额定值：6A250V
绝缘电阻：≥ 100MΩ 500V DC
接触电阻：≤ 50mΩ
耐电压：1500VAC (50-60Hz) 1 min
操作温度：-10 ℃ ~ 105℃
可焊性： 230±10℃ 3±1Sec.
耐焊性： 255±5℃ 3±1Sec.(过锡炉) 350±10℃ 3±0.5Sec.(手工焊)
耐寒性：-20±2℃ for 96h
耐湿性： 40±2℃ 90-95%RH for 96h
机械寿命： 10,000 次

Ratings: 6A250V
Insulation Resistance: ≥ 100MΩ at 500V DC
Contact Resistance: ≤ 50mΩ
Dielectric Strength: 1500VAC (50–60Hz) for 1 minute
Operating Temperature: -10°C ~ 105°C
Solderability: 230±10°C for 3±1 seconds
Solder Heat Resistance:
255±5°C for 3±1 seconds(Reflow soldering) 350±10°C for 3±0.5 seconds(Manual soldering)
Cold Resistance: -20±2°C for 96 hours
Humidity Resistance: 40±2°C, 90–95% RH for 96 hours
Mechanical Life: 10,000 cycles
